Elite Satellit HD | International Radio | Short, Medium & Long Wave Frequency

• Frequency coverage: 100-30,000 KHz, includes Shortwave, medium wave AM broadcast band and long wave; 76-90, 87-108
• Reception modes: AM, FM-stereo, Single Sideband (selectable USB/LSB) and CW
• Programmable memories: 500 user programmable with alpha labelling plus 1200 user definable country memories, for a total of 1700
• Memory scan function
• Excellent sensitivity: yielding a true high-performance receiver
• Dual conversion super heterodyne circuit: results in minimized interference through superior selectivity
• Calibrated LCD signal strength meter
• Digital Phase Lock Loop (PLL) synthesized tuning with Direct Digital Synthesis (DDS) for drift-free frequency stability and finest tuning resolution
• Tuning modes: variable-rate tuning knob, direct keypad frequency entry, up/down push buttons and auto-tuning
• Direct Shortwave band entry, allows instant access to the Shortwave band of choice
• IF passband tuning: an advanced tuning feature that functions in AM and SSB which greatly helps reject interference
• Line-in/line-out and headphone jacks
• Single sideband synchronous AM detector: selectable USB/LSB or double sideb and to minimize adjacent frequency interference and fading distortion of AM signals
• Selectable bandwidths: 7.0, 4.0, 2.5 kHz for excellent selectivity
• Digital display: large 5.7 inch square, 240 x 320 pixel, dot matrix display- shows all modes and selected functions
• Display backlighting: evenly lit backlight enables display viewing under all lighting conditions
• High dynamic range: allowing for detection of weak signals in the presence of strong signals
• Dual programmable clocks with WWV Auto-Setting
• Dual-event programmable ON/OFF timers: can be used for recording or ‘alarm clock’ function
• Stereo line-level input: allows listening to other devices such as a CD player through the Elite Satellit
• Stereo line-level output: for recording or routing the output to another device such as a home stereo
• Input for AC adapter (included), input for earphones (not included), input for antenna (not included)
• External antenna connection for the addition of auxiliary antennas, e.g. professionally engineered Shortwave antennas; long-wire Shortwave antennas; specialized AM broadcast band antennas for enthusiasts of AM DX’ing; FM broadcast band antennas
• Separate, continuous bass and treble tone controls
• Superior audio quality via a bridged type audio amplifier, providing high output power with battery operation
• Selectable AGC (Automatic Gain Control): fast and slow mode
• Built-in antenna: telescopic antenna for AM, FM and Shortwave reception
• Power source: 4 D batteries (not included) or AC adapter (included)

Dimensions
7.5" x 13" x 2.5" (H x W x D)
18.8 x 33.3 x 6.6 cm (H x W x D)
Weight: 4 lbs 3 oz (1.9 kg)
